OML24D 23.8″ Double Sided LED-edge

Brief Description:

◼ Double-Sided Display

◼ Industrial-grade PCB-mounted LEDs

◼ RGB/Addressable Modes

◼ Edge-to-Edge Design, True Flat, Easy to Clean

◼ Pole, Base and Electronic Box Design for Easy Installation


Product Detail

Product Tags

Name

23.8 Inch LED-Framed Double-Sided Monitor

Model

OML24D

LCD Panel Parameters

Display Technology

Active Matrix TFT-LCD with LED Backlight

Aspect Ratio

16 : 9

Active Area (W × H)

527.04 × 296.46 mm

Native Resolution

1920 × 1080 @ 60 Hz

Response Time (Typ.)

14 ms

Display Colors

16.7 M

Luminance (Typ.)

250 nits

Contrast Ratio (Typ.)

1000:1

Viewing Angle (Typ.)

Horizontal (left/right) CR≥10 89°/89°

Vertical (up/down) CR≥10 89°/89°

Touch Screen Parameters

 Surface Treatment

Tempered or Chemically Strengthened

Thickness (Total)

2.0 mm

Light Transmission

≥90%

Overall Parameters

Case/Bezel Color

Black

Mounting Options

Pole + Quick Mount Base, portrait mode

Outline DimensionsW×H×D

918.5 mm × 350.1 mm× 40.0 mm

Power Supply

  Input Voltage Range: +12 VDC ± 5%

On-Screen Display (OSD)

Control (back): Power, Auto, Up, Down, Menu

Power Consumption (Max.)

90 W

Operating Altitude

≤3000 m

Temperature Range

Operating: 0℃ to 40℃, storage: -20℃ to 60℃

Humidity (Non-Condensing)

Operating: 20% to 80%, storage: 10% to 90%

I/O

HDMI, HDMI, DP, USB (Type B)

Accessories

Optional

Carton Box Dimensions (2 units in one carton)

780 mm (L) × 470 mm (W) × 240 mm (H)

Weight

Net: 11 Kg
Gross: 18.5 Kg

MTBF

50,000 hours demonstrated

LED Lights Color

Multicolor

LED Lights Location

4 LED light bars (Front & Edge)

LED Controller

Built-in

Agency Approvals

CE, FCC

Warranty

3 Years



Ordering Information

Part Name

Part Number

Description

OML24D-R02000-0D2F40-2.0

23.8”, 16:9, 250 nits, non-touch, LED-framed double-sided monitor, LED lights location front & edge, portrait mode



Drawings and Spec Sheet
Spec Sheet Download
